Multilin UR8SH輸入輸出模塊 PDF資料
1.產 品 資 料 介 紹：
中文資料：
Multilin UR8SH 是 GE (General Electric) 公司的 Universal Relay (UR) 系列中的一個輸入/輸出模塊。這個模塊專門設計用于與 UR 系列保護繼電器配合使用，提供額外的數字輸入和輸出功能，增強系統的靈活性和擴展性。以下是一些關鍵特性和應用領域的概述：
主要特性：
輸入/輸出配置：
- 提供多達 8 個數字輸入和 8 個數字輸出。
- 數字輸入可用于監測外部設備的狀態或接收來自其他系統的信號。
- 數字輸出可用于控制外部設備，如繼電器或指示燈。
通信接口：
- 通過 UR 系列設備的通信接口與主繼電器進行連接。
- 支持工業標準的通信協議，如 Modbus 和 DNP3，用于數據傳輸和遠程監控。
模塊化設計：
- 模塊化設計允許根據需要添加或更換模塊，便于維護和升級。
- 可與 UR 系列的其他模塊和繼電器兼容使用，形成靈活的保護和控制系統。
配置與校準：
- 通過 UR 系列的軟件工具進行配置和校準，提供用戶友好的界面進行設置。
- 支持遠程配置和監控，減少現場操作的需求。
應用領域：
電力系統保護：
- 用于電力系統中的開關設備、變壓器、發電機等關鍵設備的保護和監控。
- 可以擴展繼電器的功能，提供額外的輸入/輸出接口以滿足復雜的保護要求。
自動化控制：
- 支持自動化控制系統，通過數字輸入/輸出接口與其他自動化設備進行集成。
- 可用于工業過程控制和系統狀態監測。
遠程監控和數據采集：
- 適用于需要遠程監控和數據采集的應用場景，通過標準通信協議與上級系統集成。
英文資料：
The Multilin UR8SH is an input/output module in GE's Universal Relay (UR) series. This module is specifically designed to be used in conjunction with UR series protective relays, providing additional digital input and output functions, enhancing the flexibility and scalability of the system. Here is an overview of some key features and application areas:
Main features:
Input/output configuration:
Provides up to 8 digital inputs and 8 digital outputs.
Digital inputs can be used to monitor the status of external devices or receive signals from other systems.
Digital output can be used to control external devices such as relays or indicator lights.
Communication interface:
Connect to the main relay through the communication interface of the UR series equipment.
Supports industry standard communication protocols such as Modbus and DNP3 for data transmission and remote monitoring.
Modular design:
Modular design allows for the addition or replacement of modules as needed, facilitating maintenance and upgrades.
Compatible with other modules and relays in the UR series, forming a flexible protection and control system.
Configuration and Calibration:
Configure and calibrate through UR series software tools, providing a user-friendly interface for settings.
Support remote configuration and monitoring, reducing the need for on-site operations.
Application areas:
Power system protection:
Used for the protection and monitoring of key equipment such as switchgear, transformers, and generators in power systems.
It can expand the functionality of relays and provide additional input/output interfaces to meet complex protection requirements.
Automated control:
Support automation control systems and integrate with other automation devices through digital input/output interfaces.
Can be used for industrial process control and system status monitoring.
Remote monitoring and data collection:
Suitable for application scenarios that require remote monitoring and data collection, integrated with higher-level systems through standard communication protocols.
2.產 品 展 示
