Multilin 369-HI-R-M-0-0電機管理繼電器
1.產 品 資 料 介 紹：
中文資料：
Multilin 369-HI-R-M-0-0 是 GE Multilin 系列中的一款高級電機管理繼電器，專為中高壓電機的保護和控制設計。它提供全面的電機保護功能，并具有強大的測量、監控和通訊能力。以下是該繼電器的詳細信息：
主要特性：
全面的電機保護功能：
- 過載保護：保護電機免受長期過載影響。
- 欠載保護：防止電機在負載過低的情況下運行。
- 堵轉保護：檢測電機堵轉情況并采取保護措施。
- 過熱保護：監測電機溫度，防止過熱損壞。
- 不平衡電流保護：監測電機三相電流的不平衡情況。
高級測量和監控：
- 實時電流和電壓監測：提供精確的電流和電壓測量。
- 功率因數測量：幫助優化電機運行效率。
- 事件記錄和故障分析：記錄和存儲電機運行事件，便于故障分析。
- 熱模型計算：通過熱模型計算，保護電機免受熱損傷。
可編程功能：
- 可編程的繼電器輸出和輸入：支持多種邏輯配置，滿足不同應用需求。
- 用戶自定義邏輯控制：靈活的控制邏輯編程能力。
- 靈活的配置選項：適應不同的電機保護需求。
通訊功能：
- 多種通訊協議：支持Modbus、DNP3等多種協議，便于與其他設備集成。
- 以太網支持：實現遠程監控和控制。
- 集成HMI（人機界面）：便捷的現場操作和狀態監測。
應用領域：
工業自動化：
- 制造業：保護和控制工業電機，確保生產線的連續性和安全性。
- 礦業：保護礦山設備電機，減少故障和停機時間。
- 鋼鐵廠：監控和保護鋼鐵生產設備的電機，保證生產過程的穩定性。
石油和天然氣：
- 鉆井平臺：保護鉆井設備電機，確保安全運行。
- 煉油廠：監控?zé)捰驮O(shè)備電機的運行狀態，防止故障和停機。
水處理設施：
- 水廠和污水處理廠：保護水處理設備電機，確保供水和污水處理系統的正常運行。
發電廠：
- 發電機保護：監控和保護發電機電機，確保發電系統的可靠性。
英文資料：
Multilin 369-HI-R-M-0-0 is an advanced motor management relay in the GE Multilin series, designed specifically for the protection and control of medium and high voltage motors. It provides comprehensive motor protection functions and has powerful measurement, monitoring, and communication capabilities. The following is the detailed information of the relay:
Main features:
Comprehensive motor protection function:
Overload protection: protects the motor from long-term overload effects.
Underload protection: prevents the motor from running under low load conditions.
Blockage protection: detect motor blockage and take protective measures.
Overheating protection: Monitor motor temperature to prevent overheating damage.
Unbalanced current protection: Monitor the imbalance of three-phase current in the motor.
Advanced measurement and monitoring:
Real time current and voltage monitoring: providing accurate current and voltage measurements.
Power factor measurement: helps optimize motor operating efficiency.
Event recording and fault analysis: Record and store motor operation events for easy fault analysis.
Thermal model calculation: Through thermal model calculation, protect the motor from thermal damage.
Programmable functions:
Programmable relay output and input: supports multiple logic configurations to meet different application requirements.
User defined logic control: flexible control logic programming ability.
Flexible configuration options: Adapt to different motor protection requirements.
Communication function:
Multiple communication protocols: Supports Modbus, DNP3, and other protocols for easy integration with other devices.
Ethernet support: enables remote monitoring and control.
Integrated HMI (Human Machine Interface): Convenient on-site operation and status monitoring.
Application areas:
Industrial automation:
Manufacturing: Protecting and controlling industrial motors to ensure the continuity and safety of production lines.
Mining: Protect mining equipment motors, reduce malfunctions and downtime.
Steel plant: Monitor and protect the motors of steel production equipment to ensure the stability of the production process.
Oil and gas:
Drilling platform: protect the motors of drilling equipment to ensure safe operation.
Refinery: Monitor the operating status of refining equipment motors to prevent malfunctions and shutdowns.
Water treatment facilities:
Water plants and sewage treatment plants: protect the motors of water treatment equipment to ensure the normal operation of water supply and sewage treatment systems.
power plant:
Generator protection: Monitor and protect the generator motor to ensure the reliability of the power generation system.
2.產 品 展 示
