MULTILIN T60K03HKHF8LH6繼電器
1.產 品 資 料 介 紹：
中文資料：
Multilin T60K03HKHF8LH6 繼電器 是 GE Multilin 系列中的一款高性能保護繼電器，主要用于變壓器保護和控制。該繼電器集成了多種先進的保護功能、通信能力和靈活的配置選項，適用于各種電力系統環境。以下是關于 Multilin T60K03HKHF8LH6 繼電器的詳細信息：
主要功能和特點
保護功能：
- 變壓器差動保護：提供快速、靈敏的變壓器差動保護，防止變壓器故障。
- 過電流保護：包括瞬時、定時限、反時限過電流保護，適應不同的應用需求。
- 接地故障保護：高靈敏度的接地故障保護，確保系統的安全運行。
- 溫度監控和保護：實時監控變壓器的溫度，防止過熱損壞。
通信能力：
- 多種通信協議：支持 Modbus、IEC 61850 等多種通信協議，便于與 SCADA 系統和其他設備集成。
- 遠程監控和控制：通過網絡或串口實現遠程監控和控制，提高系統管理效率。
配置和靈活性：
- 用戶自定義設置：提供靈活的配置選項，允許用戶根據具體需求定制保護參數和邏輯。
- 模塊化設計：支持多種模塊的擴展，滿足不同應用場景的需求。
可靠性和穩定性：
- 高可靠性設計：采用工業級設計和高質量元器件，確保在各種環境條件下的穩定運行。
- 自我診斷功能：具備自我診斷和報警功能，幫助用戶及時發現和解決問題。
顯示和操作：
- LCD顯示屏：配備清晰的 LCD 顯示屏，方便用戶查看實時數據和操作狀態。
- 本地控制鍵盤：提供便捷的本地控制和操作界面，簡化用戶操作。
應用領域
變電站：
- 變壓器保護：用于變電站中的變壓器保護，確保變壓器的安全和穩定運行。
- 綜合保護解決方案：提供變電站的全面保護和控制，提高電力系統的可靠性。
發電廠：
- 發電機變壓器保護：用于發電廠中發電機變壓器的保護，防止設備故障對發電過程的影響。
- 輔助設備保護：提供發電廠輔助設備的保護和控制，確保整體系統的高效運行。
輸電系統：
- 變壓器中繼保護：適用于輸電系統中變壓器的保護，確保長距離輸電的穩定性。
- 跨區域電網保護：提供跨區域電網的綜合保護解決方案，提高電網的可靠性和穩定性。
工業設施：
- 工業變壓器保護：用于工業設施中的變壓器保護，確保生產過程的連續性和安全性。
- 過程控制：支持工業自動化過程中的電力保護和控制功能，提高生產效率。
建筑管理系統：
- 電力設備保護：在大型建筑物中用于電力設備的保護和控制，提高建筑設施的管理效率。
- 能源管理：支持建筑管理系統的能源管理功能，優化能源使用和成本控制。
結論
Multilin T60K03HKHF8LH6 繼電器 作為 GE Multilin 系列中的高性能保護和控制設備，通過其強大的保護功能、靈活的配置選項和可靠的通信能力，在變電站、發電廠、輸電系統、工業設施和建筑管理系統等領域具有廣泛的應用。它為電力系統中的變壓器和其他關鍵設備提供了可靠的保護和控制，確保系統的安全、穩定和高效運行。
英文資料：
The Multilin T60K03HHF8LH6 relay is a high-performance protection relay in the GE Multilin series, mainly used for transformer protection and control. This relay integrates multiple advanced protection functions, communication capabilities, and flexible configuration options, suitable for various power system environments. The following is detailed information about the Multilin T60K03KHF8LH6 relay:
Main functions and features
Protection function:
Transformer differential protection: provides fast and sensitive transformer differential protection to prevent transformer faults.
Overcurrent protection: including instantaneous, timed, and inverse time overcurrent protection, suitable for different application requirements.
Ground fault protection: High sensitivity ground fault protection ensures the safe operation of the system.
Temperature monitoring and protection: Real time monitoring of transformer temperature to prevent overheating and damage.
Communication ability:
Multiple communication protocols: Supports multiple communication protocols such as Modbus and IEC 61850, making it easy to integrate with SCADA systems and other devices.
Remote monitoring and control: Implement remote monitoring and control through network or serial port to improve system management efficiency.
Configuration and flexibility:
User defined settings: Provides flexible configuration options, allowing users to customize protection parameters and logic according to specific needs.
Modular design: supports the extension of multiple modules to meet the needs of different application scenarios.
Reliability and stability:
High reliability design: Using industrial grade design and high-quality components to ensure stable operation under various environmental conditions.
Self diagnostic function: It has self diagnostic and alarm functions to help users discover and solve problems in a timely manner.
Display and operation:
LCD display screen: Equipped with a clear LCD display screen, it is convenient for users to view real-time data and operation status.
Local Control Keyboard: Provides a convenient local control and operation interface, simplifying user operations.
application area
Substation:
Transformer protection: used for transformer protection in substations to ensure the safe and stable operation of transformers.
Comprehensive protection solution: providing comprehensive protection and control for substations, improving the reliability of the power system.
power plant:
Generator Transformer Protection: Used for the protection of generator transformers in power plants to prevent equipment failures from affecting the power generation process.
Auxiliary equipment protection: Provide protection and control for auxiliary equipment in power plants to ensure efficient operation of the overall system.
Transmission system:
Transformer relay protection: suitable for protecting transformers in transmission systems, ensuring the stability of long-distance transmission.
Cross regional power grid protection: Provide comprehensive protection solutions for cross regional power grids to improve their reliability and stability.
Industrial facilities:
Industrial transformer protection: used for transformer protection in industrial facilities to ensure the continuity and safety of the production process.
Process control: Support power protection and control functions in industrial automation processes to improve production efficiency.
Building Management System:
Power equipment protection: Used in large buildings for the protection and control of power equipment, improving the management efficiency of building facilities.
Energy management: Support the energy management function of building management systems, optimize energy use and cost control.
conclusion
The Multilin T60K03KHF8LH6 relay, as a high-performance protection and control device in the GE Multilin series, has a wide range of applications in substations, power plants, transmission systems, industrial facilities, and building management systems due to its powerful protection functions, flexible configuration options, and reliable communication capabilities. It provides reliable protection and control for transformers and other critical equipment in the power system, ensuring the safe, stable, and efficient operation of the system.
2.產 品 展 示
