Multilin D30E00HCHF8FH6繼電器模塊
1.產 品 資 料 介 紹：
中文資料：
Multilin D30E00HCHF8FH6 繼電器模塊是 GE Multilin 系列中的一款繼電器模塊，主要用于電力系統的保護、控制和監測。以下是該繼電器模塊的詳細信息，包括主要特點、功能和應用領域：
主要特點和功能
保護功能
- 過流保護：監測系統中的電流，防止因過流導致的設備損壞。
- 欠壓和過壓保護：提供欠壓和過壓保護，確保設備在正常電壓范圍內運行。
- 頻率保護：監測系統頻率，確保其在允許的范圍內，防止頻率異常影響設備正常工作。
控制功能
- 自動斷路器控制：支持自動控制斷路器操作，基于實時保護信息進行自動切換。
- 故障隔離：能夠自動隔離故障區域，減少對系統其他部分的影響，提高系統的可靠性。
監控與診斷
- 實時監控：提供系統狀態的實時監控，包括電流、電壓、頻率等關鍵參數。
- 事件記錄：記錄和存儲事件和故障信息，幫助分析和診斷系統問題。
- 波形捕捉：捕捉電氣波形數據，進行詳細分析和優化保護設置。
通信接口
- 多協議支持：支持多種通信協議，如 Modbus、DNP3、IEC 61850，確保與其他設備和系統的兼容性。
- 接口選項：通常配備多種通信接口（如以太網、RS-232、RS-485），便于數據交換和系統集成。
用戶界面
- 顯示屏：配備 LCD 顯示屏，用于顯示系統狀態、參數設置和報警信息。
- 配置工具：提供圖形化配置工具，簡化參數設置和系統管理。
高可靠性
- 工業級設計：符合工業級標準，能夠在惡劣環境條件下穩定運行。
- 抗干擾能力：具備抗電磁干擾和抗噪聲能力，確保通信和操作的穩定性。
應用領域
變電站
- 設備保護：用于變電站中的設備保護，防止電流、頻率或電壓異常造成的損壞。
- 自動化控制：集成在變電站的保護系統中，實現自動化控制和故障隔離。
配電系統
- 饋線保護：為配電系統中的饋線提供保護，防止故障引發系統問題。
- 自動化控制：支持自動化控制功能，如故障隔離和恢復，提高系統的可靠性。
工業電力系統
- 設備保護：保護工業電力系統中的關鍵設備，確保其在正常運行范圍內。
- 系統監控：實時監控系統狀態，提供詳細的數據和診斷信息。
電力傳輸
- 線路保護：用于電力傳輸線路的保護，確保線路在運行中的穩定性和可靠性。
- 系統集成：與其他保護和控制系統集成，提供全面的電力系統解決方案。
總結
Multilin D30E00HCHF8FH6 繼電器模塊是一款高性能的保護和控制組件，具有過流、欠壓、過壓和頻率保護功能。其實時監控、自動控制和通信功能使其在變電站、配電系統、工業電力系統和電力傳輸領域具有廣泛的應用價值。
英文資料：
The Multilin D30E00HCHF8FH6 relay module is a relay module in the GE Multilin series, mainly used for protection, control, and monitoring of power systems. The following is the detailed information of the relay module, including its main features, functions, and application areas:
Main features and functions
Protection function
Overcurrent protection: Monitor the current in the system to prevent equipment damage caused by overcurrent.
Undervoltage and Overvoltage Protection: Provides undervoltage and overvoltage protection to ensure that the equipment operates within the normal voltage range.
Frequency protection: Monitor the system frequency to ensure it is within the allowable range and prevent abnormal frequency from affecting the normal operation of the equipment.
control function
Automatic circuit breaker control: supports automatic control of circuit breaker operation, and automatically switches based on real-time protection information.
Fault isolation: It can automatically isolate the fault area, reduce the impact on other parts of the system, and improve the reliability of the system.
Monitoring and Diagnosis
Real time monitoring: Provides real-time monitoring of system status, including key parameters such as current, voltage, frequency, etc.
Event logging: Record and store event and fault information to assist in analyzing and diagnosing system issues.
Waveform capture: Capture electrical waveform data for detailed analysis and optimization of protection settings.
communication interface
Multi protocol support: Supports multiple communication protocols such as Modbus, DNP3, IEC 61850, ensuring compatibility with other devices and systems.
Interface options: Typically equipped with multiple communication interfaces (such as Ethernet RS-232、RS-485）， Facilitating data exchange and system integration.
user interface
Display screen: equipped with an LCD display screen, used to display system status, parameter settings, and alarm information.
Configuration tool: Provides graphical configuration tools to simplify parameter settings and system management.
high reliability
Industrial grade design: Meets industrial grade standards and can operate stably in harsh environmental conditions.
Anti interference capability: It has the ability to resist electromagnetic interference and noise, ensuring the stability of communication and operation.
application area
transformer substation
Equipment protection: Used for equipment protection in substations to prevent damage caused by abnormal current, frequency, or voltage.
Automated control: integrated into the protection system of the substation to achieve automated control and fault isolation.
Distribution system
Feedline protection: provides protection for feeders in the distribution system to prevent system problems caused by faults.
Automated control: supports automated control functions such as fault isolation and recovery, improving system reliability.
Industrial power system
Equipment protection: Protect critical equipment in industrial power systems to ensure they are within normal operating range.
System monitoring: Real time monitoring of system status, providing detailed data and diagnostic information.
Power transmission
Line protection: used for the protection of power transmission lines, ensuring the stability and reliability of the lines during operation.
System integration: Integrate with other protection and control systems to provide comprehensive power system solutions.
summary
The Multilin D30E00HCHF8FH6 relay module is a high-performance protection and control component with overcurrent, undervoltage, overvoltage, and frequency protection functions. Real time monitoring, automatic control, and communication functions make it widely applicable in substations, distribution systems, industrial power systems, and power transmission fields.
