MULTILIN 369-HI-R-M-F-E電機管理繼電器
1.產 品 資 料 介 紹：
中文資料：
MULTILIN 369-HI-R-M-F-E 是 GE Multilin 系列中的一款電機管理繼電器，專為電機保護和管理設計。它用于監控電機的運行狀態，提供保護和控制功能，以確保電機的安全運行并減少故障風險。
主要功能和特點
電機保護
- 過載保護：實時監控電機負載情況，防止過載引發的設備損壞。根據設定的過載保護曲線自動斷開電機，以避免過熱或機械損壞。
- 短路保護：檢測電機電路中的短路情況，迅速切斷電源以保護電機和系統。
- 欠壓/過壓保護：提供欠壓和過壓保護，確保電機在適當?shù)碾妷悍秶鷥?nèi)運行，防止因電壓異常導致的設備損壞。
故障檢測
- 接地故障檢測：監測電機電路中的接地故障，并發出警報或自動斷開電源，以防止故障擴大。
- 溫度監測：通過連接溫度傳感器監測電機溫度，防止因過熱造成的損壞。
運行監控
- 啟動監控：記錄電機啟動過程中的數據，確保電機在啟動時不會遇到問題。
- 停機監控：監測電機的停機狀態，確保停機過程順利，避免因停機問題導致的設備損壞。
通信和控制
- 遠程監控：支持通過網絡進行遠程監控和管理，允許用戶實時查看電機狀態和進行遠程操作。
- 數據記錄：記錄電機的運行數據和事件日志，以供故障分析和維護使用。
用戶界面
- 顯示屏：配備顯示屏用于實時顯示電機狀態、報警信息和系統參數。
- 操作按鈕：提供操作按鈕用于手動控制和配置繼電器設置。
配置和調節
- 靈活設置：支持多種保護和控制參數的配置，如過載曲線、延時設置等，滿足不同電機應用的需求。
- 自診斷功能：內置自診斷功能，能夠檢測和報告系統內部的故障，確保設備正常運行。
應用領域
電力系統
- 發電廠：在發電廠中用于電機保護和管理，確保發電機和其他電機設備的安全運行。
- 變電站：提供變電站電機的保護功能，防止因電機故障導致的電力系統中斷。
工業自動化
- 制造業：保護和管理制造業中的電機，確保生產設備的穩定運行。
- 過程控制：用于過程控制系統中的電機保護，確保過程設備的可靠性和安全性。
建筑設施
- HVAC系統：在建筑設施的HVAC（暖通空調）系統中保護電機，確保暖通空調設備的正常運行。
- 電梯系統：為電梯系統中的電機提供保護和管理功能，防止電機故障影響電梯的運行安全。
水處理
- 泵站：用于水處理系統中的泵站電機保護，確保泵的安全運行和系統的穩定性。
MULTILIN 369-HI-R-M-F-E 電機管理繼電器作為一款功能全面的電機保護設備，提供了高效的電機保護和管理解決方案，確保電機在各種應用中的穩定運行和安全性。
英文資料：
MULTILIN 369-HI-R-M-F-E is a motor management relay in the GE Multilin series, designed specifically for motor protection and management. It is used to monitor the operating status of the motor, provide protection and control functions to ensure the safe operation of the motor and reduce the risk of faults.
Main functions and features
Motor protection
Overload protection: Real time monitoring of motor load to prevent equipment damage caused by overload. Automatically disconnect the motor according to the set overload protection curve to avoid overheating or mechanical damage.
Short circuit protection: detect short circuits in the motor circuit and quickly cut off the power to protect the motor and system.
Undervoltage/Overvoltage Protection: Provides undervoltage and overvoltage protection to ensure that the motor operates within the appropriate voltage range, preventing equipment damage caused by abnormal voltage.
Fault detection
Ground fault detection: Monitor ground faults in motor circuits and issue alarms or automatically disconnect power to prevent the fault from expanding.
Temperature monitoring: Monitor the motor temperature by connecting a temperature sensor to prevent damage caused by overheating.
Operation monitoring
Startup monitoring: Record data during the motor startup process to ensure that the motor does not encounter any problems during startup.
Shutdown monitoring: Monitor the shutdown status of the motor to ensure a smooth shutdown process and avoid equipment damage caused by shutdown issues.
Communication and Control
Remote monitoring: Supports remote monitoring and management through the network, allowing users to view motor status in real-time and perform remote operations.
Data recording: Record the operation data and event logs of the motor for fault analysis and maintenance purposes.
user interface
Display screen: Equipped with a display screen for real-time display of motor status, alarm information, and system parameters.
Operation buttons: Provide operation buttons for manual control and configuration of relay settings.
Configuration and adjustment
Flexible settings: Supports configuration of multiple protection and control parameters, such as overload curves, delay settings, etc., to meet the needs of different motor applications.
Self diagnostic function: Built in self diagnostic function, capable of detecting and reporting internal system faults to ensure the normal operation of the equipment.
application area
Power system
Power plant: Used for motor protection and management in power plants to ensure the safe operation of generators and other electrical equipment.
Substation: Provides protection for substation motors to prevent power system interruptions caused by motor failures.
industrial automation
Manufacturing: Protect and manage motors in the manufacturing industry to ensure stable operation of production equipment.
Process control: used for motor protection in process control systems to ensure the reliability and safety of process equipment.
Building facilities
HVAC system: Protect motors in the HVAC system of building facilities to ensure the normal operation of HVAC equipment.
Elevator system: Provides protection and management functions for the motors in the elevator system to prevent motor failures from affecting the safe operation of the elevator.
water treatment
Pump station: used for motor protection in water treatment systems, ensuring the safe operation of pumps and the stability of the system.
MULTILIN 369-HI-R-M-F-E motor management relay, as a comprehensive motor protection device, provides efficient motor protection and management solutions, ensuring the stable operation and safety of motors in various applications.
2.產 品 展 示
