Multilin F650NXBF1G1HI6數字區域控制器
1.產 品 資 料 介 紹：
中文資料：
Multilin F650NXBF1G1HI6 數字區域控制器是一款用于電力系統的高級控制設備，特別設計用于提供區域級別的控制和保護功能。它屬于 Multilin F650 系列，旨在滿足復雜電力系統中對精確控制和保護的需求。
主要功能和特點
區域控制功能
- 區域保護：用于電力系統中的特定區域，提供針對該區域的保護和控制功能?？梢栽O置多個區域，每個區域可獨立配置保護參數。
- 區域監測：實時監控區域內的電力設備狀態，提供詳細的數據和分析。
數字輸入/輸出
- 數字輸入：用于接收來自設備或系統的數字信號，如開關狀態、報警信號等。
- 數字輸出：用于發送控制信號或狀態指示，如控制斷路器、發出報警等。
保護功能
- 過載保護：防止設備因長時間過載而受損。
- 短路保護：檢測并響應區域內的短路故障，保護設備免受嚴重損壞。
- 接地故障保護：監測區域內的接地故障，提供必要的保護措施。
- 過電壓/欠電壓保護：確保區域設備在電壓異常情況下的安全運行。
控制功能
- 自動控制：根據設定的條件進行自動控制操作，如自動啟停設備。
- 遠程控制：支持遠程操作和控制，提高系統的靈活性和管理效率。
通信接口
- 多種協議支持：支持常見的通信協議，如Modbus、DNP3、IEC 61850等，方便與SCADA系統和其他設備的集成。
- 數據傳輸：實現數據的遠程監控和管理，支持實時數據傳輸和控制。
用戶界面
- 圖形化顯示：提供直觀的顯示界面，簡化操作和配置過程。
- 靈活配置：允許用戶根據實際需要配置設備的保護和控制參數。
高可靠性
- 隔離保護：具有電氣隔離保護功能，防止干擾和故障傳播。
- 抗干擾能力：設計考慮了工業環境的要求，具備較強的耐用性和抗干擾能力。
應用領域
變電站自動化
- 區域保護和控制：在變電站中為不同的區域提供保護和控制，確保變電站的穩定運行。
- 設備監控：監控變電站內的設備狀態，提供故障預警和維護支持。
工業電力系統
- 設備保護：為工業設施中的特定區域提供保護功能，如電動機、變壓器等。
- 過程控制：用于工業自動化系統中的區域控制，確保生產過程的安全和穩定。
配電系統
- 區域保護：保護配電網絡中的特定區域，防止故障蔓延。
- 控制和監測：實現對配電系統的控制和監測，優化系統運行和維護。
發電廠
- 發電機和設備保護：在發電廠中為發電機和其他關鍵設備提供區域保護。
- 系統管理：監控和控制發電廠內的各個區域，提高系統的可靠性和運行效率。
Multilin F650NXBF1G1HI6 數字區域控制器通過其先進的控制、保護和監測功能，為電力系統提供了靈活的區域級別解決方案，幫助用戶提高系統的安全性、穩定性和管理效率。
英文資料：
The Multilin F650NXBF1G1HI6 digital area controller is an advanced control device designed specifically for providing area level control and protection functions in power systems. It belongs to the Multilin F650 series, designed to meet the demand for precise control and protection in complex power systems.
Main functions and features
Regional control function
Regional protection: Used for specific areas in the power system, providing protection and control functions for that area. Multiple regions can be set, and each region can independently configure protection parameters.
Regional monitoring: Real time monitoring of the status of power equipment within the area, providing detailed data and analysis.
Digital input/output
Digital input: used to receive digital signals from devices or systems, such as switch status, alarm signals, etc.
Digital output: used to send control signals or status indications, such as controlling circuit breakers, issuing alarms, etc.
Protection function
Overload protection: prevents equipment from being damaged due to prolonged overload.
Short circuit protection: detects and responds to short circuit faults within the area, protecting equipment from serious damage.
Ground fault protection: Monitor ground faults within the monitoring area and provide necessary protective measures.
Overvoltage/undervoltage protection: Ensure the safe operation of equipment in the area under abnormal voltage conditions.
control function
Automatic control: Perform automatic control operations based on set conditions, such as automatically starting and stopping equipment.
Remote control: supports remote operation and control, improving system flexibility and management efficiency.
communication interface
Multiple protocol support: Supports common communication protocols such as Modbus, DNP3, IEC 61850, etc., facilitating integration with SCADA systems and other devices.
Data transmission: Implement remote monitoring and management of data, support real-time data transmission and control.
user interface
Graphic display: Provides an intuitive display interface, simplifying the operation and configuration process.
Flexible configuration: allows users to configure the protection and control parameters of the device according to their actual needs.
high reliability
Isolation protection: It has electrical isolation protection function to prevent interference and fault propagation.
Anti interference capability: The design considers the requirements of industrial environments and has strong durability and anti-interference ability.
application area
substation automation
Regional protection and control: Provide protection and control for different areas in the substation to ensure stable operation of the substation.
Equipment monitoring: Monitor the status of equipment in the substation, provide fault warning and maintenance support.
Industrial power system
Equipment protection: provides protection functions for specific areas in industrial facilities, such as motors, transformers, etc.
Process control: used for area control in industrial automation systems to ensure the safety and stability of the production process.
Distribution system
Regional protection: Protecting specific areas in the distribution network to prevent the spread of faults.
Control and Monitoring: Implement control and monitoring of the power distribution system, optimize system operation and maintenance.
power plant
Generator and equipment protection: Provide area protection for generators and other critical equipment in power plants.
System management: Monitor and control various areas within the power plant to improve system reliability and operational efficiency.
The Multilin F650NXBF1G1HI6 digital area controller provides flexible area level solutions for power systems through its advanced control, protection, and monitoring functions, helping users improve system safety, stability, and management efficiency.
2.產 品 展 示
