KJ2201X1-BA1串行鏈路模塊,KJ2201X1-BA1實驗數據
如果HSS模塊與MFP模塊失去通信，手動控制電路使操作員能夠手動
改變執行器位置。HSS模塊提供兩個24 VDC隔離數字輸入，作為來自手動站（按鈕、觸點等）。這些輸入連接到微處理器。微處理器增量
或在以下情況下減少對伺服閥的位置需求：操作員激活觸點。圖2-5為示意圖一個典型的隔離數字輸入電路。跳閘偏差是第三個數字輸入。
KJ2201X1-BA1串行鏈路模塊跳閘偏置輸入信號為發送至位置誤差電路（見圖2-3）。激活跳閘偏差輸入將執行器驅動至0%位置（完全關閉）關閉。硬手動是一種隔離輸出為外部指示燈（LED）或驚恐指示器通知操作員模塊處于
硬手動模式。本節涵蓋靜電感應裝置、終端裝置或模塊安裝、初步雙列直插式開關設置、跳線設置、液壓伺服（HSS）的正確處理模塊安裝和配置。本節中的步驟為LVDT/致動器校準和調諧。
If the HSS module loses communication with the MFP module,
the manual control circuitry enables the operator to manually
change actuator position. The HSS module provides two
24 VDC isolated digital inputs as raise/lower commands from
a manual station (pushbuttons, contacts, etc.). These inputs
connect to the microprocessor. The microprocessor increments
or decrements a position demand to the servo valve when the
operator activates the contacts. Figure 2-5 shows a schematic
of a typical isolated digital input circuit.
Trip bias is the third digital input. The trip bias input signal is
sent to the position error circuit (see Figure 2-3). Activating the
trip bias input drives the actuator to the zero percent position
(fully closed) for shutdown. Hard manual is an isolated output
that provides a connection for an external indicator (LED) or
alarm. The indicator notifies the operator that the module is in
the hard manual mode.This section covers the proper handling of electrostatic sensitive devices, termination unit or module installation, preliminary dipswitch settings, jumper settings, hydraulic servo (HSS)
module installation and configuration. The steps in this section prepare the module for LVDT/actuator calibration and
tuning.
