HONEYWELL 05701-A-0502框架,05701-A-0502參數說明
為稱重傳感器定義了坐標系。這在力計算中用于推導力稱重傳感器主方向上的組件。
其中，方向代號R、V和A被識別為力分量F的后綴，這表示各個方向上的力分量。后綴R可以省略，當測量方向由上下文暗示時。關于本附錄本附錄描述了稱重傳感器安裝的設計程序。
包括以下部分：?基本應用注意事項
?設計稱重傳感器安裝（分步指南）
?安裝要求
HONEYWELL 05701-A-0502框架?力和纏繞增益計算–水平安裝–傾斜安裝–單側測量
?安裝稱重傳感器
?技術數據
?圖紙–電纜圖–稱重傳感器延長電纜的安裝說明–尺寸圖–裝配圖
B、 2基本應用注意事項每個應用程序都有自己的需要考慮的個人需求；雖然有一些基本的考慮因素往往會重復出現。
?涉及什么類型的過程（造紙、轉化等）？環境是否要求（溫度、化學品等）？
?張力測量的目的是什么；指示或閉環控制？是否有任何具體的精度要求？
?機器的設計是什么樣的？是否有可能修改設計，為了安裝最合適的稱重傳感器，還是機器設計是固定的？
?作用在輥上的力是什么（大小和方向）？它們可以通過重新設計來改變嗎？如果徹底解決這些問題，安裝很可能成功。
然而，需要測量精度的程度定義了以下要求：設計稱重傳感器裝置。
