Overview
The S710D data transceiver provides two-way transmission of
multiprotocol data over two multimode fibers.
Data Translation
The S710D also features the unique data translation function that
allows input of one data format and output of a different format.
Data formats are selected during installation and can be easily
changed in the field via rotary switch.
Superior Diagnostics
The SMARTS? diagnostic technology provides an extensive array
of system status LEDs. The integrity of the data paths can be tested
with a built-in data transmission test generator. It is not necessary
to connect to an external data device.Standard Features
Two-way data transmission over two multimode fibers Supports
multiprotocol data formats including RS-232, TTL, RS-422,
RS-485, Manchester, Biphase, and SensorNet
Unique data translation function
User-configurable data format
13 dB optical budget
Optical AGC
SMARTS? diagnostics
Standalone and rack configurations
