3BSE008516R1 AI810 模擬輸入量模塊
1.產 品 資 料 介 紹：
中文資料：
3BSE008516R1 AI810是一款由ABB公司生產的模擬輸入量模塊，主要用于工業自動化系統中的模擬信號采集和處理。以下是該模塊的主要特點和應用領域：
產品特點
多通道輸入：
- 提供8個單端模擬輸入通道，可用于連接多種傳感器和設備，進行信號采集。
高精度：
- 支持12位分辨率，提供高精度的模擬信號測量，確保數據的準確性。
多種輸入類型：
- 支持多種類型的模擬輸入信號，如電壓（0-10V）和電流（4-20mA），適應不同的應用需求。
隔離設計：
- 模塊設計中包含通道間隔離和通道對地隔離，增強抗干擾能力，提高系統的穩定性和安全性。
模塊化設計：
- 采用模塊化結構，便于安裝、維護和擴展，用戶可以根據實際需求靈活配置系統。
診斷功能：
- 具備自診斷功能，可以實時監控輸入信號和模塊狀態，提供故障檢測和報警功能，便于維護和管理。
兼容性：
- 兼容ABB的各類控制系統，便于集成到現有的自動化系統中，提升系統的整體性能。
應用領域
過程控制：
- 用于石油化工、冶金、制藥等行業的過程控制系統中，進行關鍵參數的監測和控制。
電力行業：
- 在發電廠和變電站中，采集和處理各種模擬信號，如電流、電壓和溫度信號，進行設備監控和保護。
水處理：
- 應用于污水處理廠、自來水廠等水處理系統中，監測水質參數和設備運行狀態，確保水處理過程的高效和安全。
制造業：
- 在汽車、電子、食品等制造行業的自動化生產線中，采集和處理各種傳感器信號，實現精確控制和質量監測。
建筑自動化：
- 用于智能建筑的能源管理系統中，監測和控制暖通空調系統、照明系統等，提高建筑的能源效率和舒適度。
環境監測：
- 在環境監測系統中，采集各種環境參數，如溫度、濕度和污染物濃度，進行實時監測和數據分析。
3BSE008516R1 AI810模擬輸入量模塊以其高精度、多通道和高可靠性的特點，廣泛應用于各個工業自動化領域，提供穩定可靠的模擬信號采集和處理解決方案。
英文資料
3BSE008516R1 AI810 is an analog input module produced by ABB, mainly used for analog signal acquisition and processing in industrial automation systems. The following are the main features and application areas of this module:
Product features
Multi channel input:
Provide 8 single ended analog input channels, which can be used to connect various sensors and devices for signal acquisition.
High precision:
Supports 12 bit resolution and provides high-precision analog signal measurement to ensure data accuracy.
Multiple input types:
Supports various types of analog input signals, such as voltage (0-10V) and current (4-20mA), to meet different application requirements.
Isolation design:
The module design includes inter channel isolation and channel to ground isolation to enhance anti-interference ability, improve system stability and security.
Modular design:
Adopting a modular structure, it is easy to install, maintain, and expand, and users can flexibly configure the system according to their actual needs.
Diagnostic function:
Equipped with self diagnostic function, it can monitor input signals and module status in real time, provide fault detection and alarm functions, and facilitate maintenance and management.
Compatibility:
Compatible with various ABB control systems, facilitating integration into existing automation systems and improving overall system performance.
application area
Process control:
Used in process control systems for industries such as petrochemicals, metallurgy, and pharmaceuticals to monitor and control key parameters.
Electricity industry:
In power plants and substations, various analog signals such as current, voltage, and temperature are collected and processed for equipment monitoring and protection.
Water treatment:
Applied in water treatment systems such as sewage treatment plants and water supply plants, monitoring water quality parameters and equipment operation status to ensure efficient and safe water treatment processes.
manufacturing
In the automated production lines of industries such as automobiles, electronics, and food, various sensor signals are collected and processed to achieve precise control and quality monitoring.
Building automation:
In the energy management system used in intelligent buildings, monitoring and controlling HVAC systems, lighting systems, etc., to improve the energy efficiency and comfort of the building.
Environmental monitoring:
In the environmental monitoring system, various environmental parameters such as temperature, humidity, and pollutant concentration are collected for real-time monitoring and data analysis.
The 3BSE008516R1 AI810 analog input module is widely used in various industrial automation fields due to its high precision, multi-channel, and high reliability, providing stable and reliable analog signal acquisition and processing solutions.
2.產 品 展 示
3.產 品 展 示
