IS200TRLYH1BGF繼電器端子板
1.產 品 資 料 介 紹：
中文資料：
IS200TRLYH1BGF繼電器端子板是GE公司生產的一款產品，它主要用于Mark VI汽輪機控制系統中的終端繼電器卡。以下是關于該產品的詳細特點描述：
- 設計特點：
- 繼電器連接：該端子板配備有繼電器插槽，用于連接和控制繼電器。繼電器是一種電子開關設備，用于在電路中控制電流的流動。
- 輸入和輸出：該端子板具有輸入和輸出連接點，用于將信號傳輸?shù)嚼^電器并從繼電器中接收信號。這些輸入和輸出可以與其他設備和系統連接，以實現控制和監測。
- 電路保護：一些終端板可能具有電路保護功能，以防止電流過載或其他電氣問題。
- 物理描述：
- 端子數量：IS200TRLYH1BGF在其左邊緣包含兩個大型黑色端子板，每個接線板都有24個銀色金屬端子，總共48個終端。每一個端子都用白字標在端子板上。
- 連接器端口：該板在右邊界有四個連接器端口，其中三個連接器端口在邊緣垂直對齊，最后一個與底部的連接器端口平行。
- 繼電器排列：在IS200TRLYH1BGF的中心附近有一長串繼電器，它們是白色和黑色的，帶有形狀像立方體的透明蓋子。這些元件用黑線連接到PCB上。其中，五個繼電器垂直排列在板的上半部分，另外五個繼電器排列在PCB的下半部分。
- 其他元件：每個繼電器的兩側是一個黑色的圓形晶體管。與每個晶體管配對的是一個圓形的紅色MOV或金屬氧化物變阻器。
- 功能特點：
- 表決線圈驅動反饋：該端子板可能具備表決線圈驅動反饋功能，確保繼電器動作的準確性和可靠性。
- MOV抑制：金屬氧化物變阻器（MOV）的引入可能用于限制電壓瞬變和浪涌，以保護電路和繼電器免受損壞。
- 診斷和監測：
- 該產品可能具有先進的診斷和監測功能，如繼電器輸出（線圈電流）的監控、電磁閥勵磁電壓的監測、繼電器觸點電壓的監測等，以確保系統的正常運行和故障預警。
英文資料
IS200TRLYH1BGF relay terminal board is a product produced by GE, mainly used for terminal relay cards in Mark VI turbine control systems. The following is a detailed description of the product's features:
Design features:
Relay connection: This terminal board is equipped with relay slots for connecting and controlling relays. A relay is an electronic switching device used to control the flow of current in a circuit.
Input and Output: This terminal board has input and output connection points for transmitting signals to and receiving signals from relays. These inputs and outputs can be connected to other devices and systems for control and monitoring.
Circuit protection: Some terminal boards may have circuit protection functions to prevent current overload or other electrical problems.
Physical description:
Terminal quantity: IS200TRLYH1BGF contains two large black terminal blocks on its left edge, each with 24 silver metal terminals, for a total of 48 terminals. Each terminal is marked with white letters on the terminal board.
Connector Ports: The board has four connector ports on the right boundary, with three connector ports aligned vertically at the edges and the last parallel to the bottom connector port.
Relay arrangement: There is a long string of relays near the center of IS200TRLYH1BGF, which are white and black with transparent covers shaped like cubes. These components are connected to the PCB with black wires. Among them, five relays are arranged vertically in the upper half of the board, and the other five relays are arranged in the lower half of the PCB.
Other components: There are black circular transistors on both sides of each relay. Paired with each transistor is a circular red MOV or metal oxide varistor.
Functional features:
Voting coil drive feedback: This terminal board may have voting coil drive feedback function to ensure the accuracy and reliability of relay action.
MOV suppression: The introduction of metal oxide varistors (MOVs) may be used to limit voltage transients and surges to protect circuits and relays from damage.
Diagnosis and monitoring:
This product may have advanced diagnostic and monitoring functions, such as monitoring relay output (coil current), electromagnetic valve excitation voltage, relay contact voltage, etc., to ensure the normal operation of the system and fault warning.
2.產 品 展 示
3.產 品 展 示
