GJR2395400R1210卡件,GJR2395400R1210培訓教程
模擬輸出（AO）模塊接收
來自主處理器的輸出信號
三個通道中的每個通道上的模塊。每個對一組數據進行投票，并得到一個健康的選擇通道來驅動輸出。
每個模塊監控自己的電流輸出（作為輸入電壓）和main tain a internal voltage reference to
提供自校準和模塊健康信息。
模塊上的每個通道都有一個電流用于驗證模擬的準確性和存在性
獨立于負載存在的信號或頻道選擇。模塊的設計可防止未選擇的通道
從驅動模擬信號到領域此外，正在進行的診斷
GJR2395400R1210卡件在每個通道上執行，并且模塊電路。任何故障診斷測試停用故障
引導并激活故障指示器和機箱警報。這個模塊故障指示燈僅指示通道故障，而非模塊故障。
模塊繼續使用多達兩個通道運行失敗。提供開環檢測通過負載指示器，如果
模塊無法將電流驅動到一個或多個輸出。
該模塊提供了冗余功能回路電源與單獨
稱為PWR1的電源和保險絲指示燈和PWR2。外部回路電源
模擬輸出電源必須由用戶提供。如果開環
在一個或多個輸出點上檢測到。如果回路電源接通，PWR1和PWR2接通存在。
GJR2395400R1210卡件AO模塊支持熱備盤能力，允許在線更換出現故障的模塊。
AO模塊需要單獨的外部帶電纜的終端面板（ETP）
Tricon背板接口。每個模塊通過機械鍵連接到防止在已配置機箱。
3805H型模塊經過修改以支持增加的感應
Analog Output (AO) modules receive
output signals from the Main Processor
module on each of three channels. Each
set of data is then voted and a healthy
channel is selected to drive the outputs.
Each module monitors its own current
outputs (as input voltages) and main
tains an internal voltage reference to
provide self-calibration and module
health information.
Each channel on a module has a current
loopback circuit which verifies the
accuracy and presence of analog
signals independently of load presence
or channel selection. The module’s
design prevents a non-selected channel
from driving an analog signal to the
field. In addition, ongoing diagnostics
are performed on each channel and
circuit of the module. Failure of any
diagnostic test deactivates the faulty
channel and activates the Fault indi
cator and the chassis alarm. The
module Fault indicator merely indicates
a channel fault, not a module failure.
The module continues to operate prop
erly with as many as two channels
failed. Open loop detection is provided
by a LOAD indicator which activates if
the module is unable to drive current to
one or more outputs.
The module provides for redundant
loop power sources with individual
power and fuse indicators called PWR1
and PWR2. External loop power
supplies for analog outputs must be
provided by the user. A LOAD indi
cator activates if an open loop is
detected on one or more output points.
PWR1 and PWR2 are on if loop power
is present.
AO modules support hot- spare capa
bility, which allows online replacement
of a faulty module.
AO modules require a separate external
termination panel (ETP) with a cable
interface to the Tricon backplane. Each
module is mechanically keyed to
prevent improper installation in a
configured chassis.
The Model 3805H module has been
modified to support increased inductive
