TRICONEX MP2101底板,MP2101使用方法教程
PI模塊沒有
提供合計功能
為測量速度而優化
旋轉設備。有關脈沖累加，MP2101。
繼電器輸出模塊
3636R和3636T型繼電器
輸出（RO）模塊是非三重模塊，用于非關鍵與不兼容的點“高端”固態輸出開關。
例如，與報警器面板接口。繼電器輸出模塊
接收來自主電源的輸出信號
TRICONEX MP2101底板
三個通道中每個通道上的處理器。
然后對三組信號進行表決，
投票數據用于驅動
32個獨立繼電器。
每個輸出都有一個環回電路
驗證每個
繼電器開關獨立于負載壓力，而持續的診斷測試
單元任何診斷激活失敗都會激活故障指示燈，反過來
激活底盤警報。
繼電器輸出模塊隨附
常開（NO）觸點。它
支持熱備盤模塊和
需要單獨的外部終端
帶電纜接口的面板（ETP）
Tricon背板。
The PI module does not
provide a totalization capability—it is
optimized for measuring the speed of
rotation equipment. For pulse totaliza
tion, see Model 3515 on page 38.
Relay Output Module
The Model 3636R and 3636T Relay
Output (RO) Modules are non-tripli
cated modules for use on non-critical
points which are not compatible with
“high-side” solid-state output switches.
An example is interfacing with annun
ciator panels. The Relay Output module
receives output signals from the Main
Processors on each of three channels.
The three sets of signals are then voted,
and the voted data is used to drive the
32 individual relays.
Each output has a loopback circuit
which verifies the operation of each
relay switch independently of the pres
ence of a load, while ongoing diagnos
tics test the operational status of the
module. Failure of any diagnostic acti
vates the Fault indicator, which in turn
activates the chassis alarm.
The Relay Output module comes with
normally open (NO) contacts. It
supports hot-spare modules and
requires a separate external termination
panel (ETP) with a cable interface to
the Tricon backplane.
