MOTOROLA MVME162-213微處理器模塊
1.產 品 資 料 介 紹：
中文資料：
MOTOROLA MVME162-213微處理器模塊是一款高性能、高可靠性的嵌入式控制器，屬于Emerson/Motorola MVME162系列雙高VME模塊。以下是關于該模塊的詳細信息和特點：
- 處理器與內存：
- MVME162-213基于MC68EC040或可選的MC68LC040微處理器，這兩款微處理器為系統提供了強大的處理能力。
- 內存方面，該模塊提供1MB、4MB或8MB的校驗保護DRAM，以及512Kb的SRAM（帶電池備份），為系統提供充足的內存資源。
- 時鐘與備份：
- 配備一個TOD時鐘（帶電池備份），確保時間的準確性和穩定性，在電源中斷的情況下也能保持時間信息。
- 通信接口：
- MVME162-213支持多種I/O接口和通信協議，包括兩個串行端口（EIA-232-D和EIA-232-D/EIA-530），以及可選的LAN ethernet收發接口（DMA）和SCSI總線接口（DMA），使數據傳輸更加高效和靈活。
- 系統支持：
- 該模塊支持多種操作系統，如VxWorks和Linux等，使得MVME162-213能夠在不同的應用環境中進行開發和部署，滿足各種嵌入式系統和工業自動化應用的需求。
- 擴展性與開放性：
- MVME162-213遵循開放計算的原則，包括模塊化、可擴展性、可移植性和互操作性，使得它在系統集成和擴展方面更加靈活和方便。
- 工業級設計：
- MOTOROLA MVME162-213通信模塊通常采用工業級設計，具有抗振動、抗沖擊、耐高溫等特性，適用于工業環境中的長期穩定運行。
- 技術規格（示例）：
- 在一個特定的配置中，MVME162-213可能配備25 MHz MC68LC040微處理器、4 MB DRAM、128 KB SRAM、1 MB Flash Memory等，具體配置可能因型號和應用需求而異。
- 應用場景：
- MVME162-213在工業自動化和控制應用中具有很高的應用價值，可以滿足各種高精度、高穩定性的需求，特別適用于需要高性能微處理器和豐富內存資源的嵌入式系統。
總之，MOTOROLA MVME162-213微處理器模塊以其高性能、高可靠性、豐富的功能和靈活的擴展性，成為工業自動化和嵌入式系統領域的優選解決方案。
英文資料
The MOTOROLA MVME162-213 microprocessor module is a high-performance and highly reliable embedded controller, belonging to the Emerson/Motorola MVME162 series dual high VME module. The following is detailed information and features about this module:
Processor and memory:
The MVME162-213 is based on the MC68EC040 or optional MC68LC040 microprocessor, which provide powerful processing power for the system.
In terms of memory, this module provides 1MB, 4MB, or 8MB of checksum protected DRAM, as well as 512Kb of SRAM (with battery backup), providing sufficient memory resources for the system.
Clock and backup:
Equipped with a TOD clock (with battery backup) to ensure the accuracy and stability of time, and to maintain time information even in the event of power interruption.
Communication interface:
MVME162-213 supports multiple I/O interfaces and communication protocols, including two serial ports (EIA-232-D and EIA-232-D/EIA-530), as well as optional LAN Ethernet transceiver interface (DMA) and SCSI-bus interface (DMA), making data transmission more efficient and flexible.
System support:
This module supports multiple operating systems, such as VxWorks and Linux, enabling MVME162-213 to be developed and deployed in different application environments, meeting the needs of various embedded systems and industrial automation applications.
Scalability and Openness:
MVME162-213 follows the principles of open computing, including modularity, scalability, portability, and interoperability, making it more flexible and convenient in system integration and expansion.
Industrial grade design:
The MOTOROLA MVME162-213 communication module typically adopts an industrial grade design, which has characteristics such as vibration resistance, impact resistance, and high temperature resistance, making it suitable for long-term stable operation in industrial environments.
Technical specifications (example):
In a specific configuration, MVME162-213 may be equipped with a 25 MHz MC68LC040 microprocessor, 4 MB DRAM, 128 KB SRAM, 1 MB Flash Memory, etc. The specific configuration may vary depending on the model and application requirements.
Application scenario:
MVME162-213 has high application value in industrial automation and control applications, meeting various high-precision and high stability requirements, especially suitable for embedded systems that require high-performance microprocessors and rich memory resources.
In summary, the MOTOROLA MVME162-213 microprocessor module has become the preferred solution for industrial automation and embedded systems due to its high performance, reliability, rich functionality, and flexible scalability.
2.產 品 展 示
3.產 品 展 示
