3BHB018162R0001信號處理模塊,5SHY4045L0001可控硅模塊
主處理器模塊
3008型主處理器（MP）包括
適用于3BHB018162R0001及更高版本系統。有關詳細規范，
對于Tricon系統。
三個MPs必須安裝在每個Tricon系統的主機箱。
每個MP獨立通信并執行用戶編寫的控制程序。
事件順序（SOE）和時間同步
在每次掃描期間，MPs檢查狀態的指定離散變量
更改稱為事件。當事件發生時，MPs保存當前
中的變量狀態和時間戳SOE塊的緩沖區。如果多個Tricon系統
通過NCMs連接，時間同步功能確保
有效SOE的一致時間基礎
時間戳。詳見第72頁5SHY4045L0001 3BHB018162R0001
信息
診斷
廣泛的診斷驗證
每個MP、輸入/輸出模塊和
通信信道。轉瞬即逝的
記錄故障并通過
硬件多數表決電路。
持續性故障得到診斷
錯誤模塊被熱更換。
MP診斷執行以下任務：
?驗證固定程序內存和
靜態RAM
Main Processor Modules
Model 3008 Main Processors (MP) are
available for Tricon v9.6 and later
systems. For detailed specifications,
see the Planning and Installation Guide
for Tricon Systems.
Three MPs must be installed in the
Main Chassis of every Tricon system.
Each MP independently communicates
with its I/O subsystem and executes the
user-written control program.
Sequence of Events (SOE)
and Time Synchronization
During each scan, the MPs inspect
designated discrete variables for state
changes known as events. When an
event occurs, the MPs save the current
variable state and time stamp in the
buffer of an SOE block.If multiple Tricon systems are
connected by means of NCMs, the time
synchronization capability ensures a
consistent time base for effective SOE
time-stamping. See page 72 for more
information.
Diagnostics
Extensive diagnostics validate the
health of each MP, I/O module and
communication channel. Transient
faults are recorded and masked by the
hardware majority-voting circuit.
Persistent faults are diagnosed and the
errant module is hot-replaced.
MP diagnostics perform these tasks:
? Verify fixed-program memory and
static RAM
