3BSE043664R1底座模塊,3BSE043664R1配置教程
光纖遙控器
擴展器模塊（RXM）用于擴展機箱up的操作至距離
主機箱抗靜電和電磁干擾。TP867 3BSE043664R1
接口模塊?HART模擬輸入接口
模塊充當4-20 mA模擬輸入點
現場HART智能設備和HART主機軟件在個人計算機
?HART模擬輸出接口
模塊充當
4-20 mA模擬輸出點
現場HART智能設備和
HART主機軟件在3BSE043664R1底座模塊,
個人計算機
輸入/輸出模塊
?數字輸入模塊接收
這些標稱值的離散信號
電壓：115 VAC/VDC，48
VAC/VDC和24 VAC/VDC。全部的
TMR中提供電壓
模塊。非TMR模塊包括
提供24 VDC和48 VDC
只有速度輸入和總計
模塊也可用。
?監控?cái)?shù)字輸出模塊
產生離散輸出信號
這些標稱電壓
現場診斷覆蓋范圍
電路和負載裝置：115 VAC，
120 VDC、48 VDC和24 VDC。
?數字輸出模塊產生
這些的離散輸出信號
標稱電壓：115 VAC，120
Fiber-Optic Remote
Extender Modules (RXM)
For operation of Expansion Chassis up
to 7.5 miles (12 kilometers) away from
the Main Chassis, with exceptional
immunity against electro-static and
electro-magnetic interference.
Interface Modules
?
HART Analog Input Interface
Modules act as an interface between
4-20 mA analog input points from
HART smart devices in the field and
HART Host software running on a
PC.
?
HART Analog Output Interface
Modules act as an interface between
4-20 mA analog output points from
HART smart devices in the field and
HART Host software running on a
PC.
I/O Modules
?
Digital Input Modules receive
discrete signals of these nominal
voltages: 115 VAC/VDC, 48
VAC/VDC, and 24 VAC/VDC. All
voltages are available in TMR
modules. Non-TMR modules are
available in 24 VDC and 48 VDC
only. Speed input and totalization
modules are also available.
?
Supervised Digital Output Modules
produce discrete output signals of
these nominal voltages, with
diagnostic coverage of the field
circuit and load device: 115 VAC,
120 VDC, 48 VDC, and 24 VDC.
?
Digital Output Modules produce
discrete output signals of these
nominal voltages: 115 VAC, 120
