NI SCXI-1600數據采集模塊
1.產 品 資 料 介 紹：
中文資料：
NI SCXI-1600數據采集模塊是一款功能全面的數據采集設備，以下是對其特點、規格和應用的詳細解析：
主要特點
- 高性能數據采集：NI SCXI-1600具有高達352個通道、16位ADC，采樣率高達200 kS/s，能夠高效、準確地采集模擬信號。
- 全功能控制和數據模塊：該模塊不僅用于數據采集，還可用作SCXI數字I/O、開關、模擬輸入和模擬輸出模塊的全功能控制和數據模塊。
- 易用性：NI SCXI-1600支持即插即用，安裝于SCXI機箱中后，可方便地為其他SCXI模塊提供時鐘、校準和外部數字觸發連接。
- 廣泛的信號兼容性：能夠接收來自其他模塊的模擬信號，并通過USB端口進行數字化、放大和傳輸，兼容多種信號類型，如RTD、熱電偶、應變計、電流源和電壓等。
- 強大的系統定時控制器：使用National Instruments DAQ-STC作為系統定時控制器，確保數據采集的準確性和穩定性。
規格參數
- 總線類型：SCXI
- 操作系統/對象：支持Windows、實時系統、Linux
- 測量類型：包括電流、溫度、熱電偶、電壓等
- 通道數：32個（模擬輸入通道）
- 采樣率：最高200 kS/s
- 帶寬：10 kHz
- 信號調理：支持0-20 mA電流輸入、低通濾波等功能
應用領域
NI SCXI-1600數據采集模塊廣泛應用于各種需要高精度數據采集和處理的領域，如工業自動化、環境監測、科研實驗等。其高采樣率、多通道和易用性等特點使其成為工程師和技術人員不可或缺的數據采集工具。
附加信息
- 兼容性：該模塊兼容USB，支持供電或熱插入U(xiǎn)SB端口，便于與其他設備連接和集成。
- 校準與監控：前面板配備了LED指示燈，用于監控機箱的V+和V-導軌狀態以及數據采集模塊的活動和就緒狀態。此外，還提供了一個專用的BNC連接器用于校準。
- 軟件支持：NI設備使用NIDAQmx驅動軟件運行，該軟件與多種軟件包/應用程序開發環境（如LabVIEW、LabWindows/CVI或Measurement Studio）兼容，方便用戶進行數據采集和分析。
綜上所述，NI SCXI-1600數據采集模塊以其高性能、易用性和廣泛的應用領域，成為數據采集領域的一款重要設備。
英文資料
The NI SCXI-1600 data acquisition module is a comprehensive data acquisition device. The following is a detailed analysis of its characteristics, specifications, and applications:
main features
High performance data acquisition: The NI SCXI-1600 has up to 352 channels, 16 bit ADC, and a sampling rate of up to 200 kS/s, enabling efficient and accurate acquisition of analog signals.
Full function control and data module: This module is not only used for data acquisition, but can also be used as a full function control and data module for SCXI digital I/O, switches, analog inputs, and analog outputs.
Usability: The NI SCXI-1600 supports plug and play, and when installed in the SCXI chassis, it can easily provide clock, calibration, and external digital trigger connections for other SCXI modules.
Wide signal compatibility: capable of receiving analog signals from other modules and digitizing, amplifying, and transmitting them through USB ports, compatible with various signal types such as RTD, thermocouple, strain gauge, current source, and voltage.
Powerful system timing controller: Use National Instruments DAQ-STC as the system timing controller to ensure the accuracy and stability of data collection.
Specification parameters
Bus type: SCXI
Operating system/object: Supports Windows, real-time systems Linux
Measurement types: including current, temperature, thermocouple, voltage, etc
Number of channels: 32 (analog input channels)
Sampling rate: up to 200 kS/s
Bandwidth: 10 kHz
Signal conditioning: Supports 0-20 mA current input, low-pass filtering, and other functions
application area
The NI SCXI-1600 data acquisition module is widely used in various fields that require high-precision data acquisition and processing, such as industrial automation, environmental monitoring, scientific research experiments, etc. Its high sampling rate, multi-channel, and ease of use make it an indispensable data collection tool for engineers and technicians.
Additional information
Compatibility: This module is compatible with USB and supports power or hot insertion into USB ports, making it easy to connect and integrate with other devices.
Calibration and monitoring: The front panel is equipped with LED indicator lights to monitor the V+and V - rail status of the chassis, as well as the activity and readiness status of the data acquisition module. In addition, a dedicated BNC connector is provided for calibration.
Software support: NI devices run using NIDAQmx driver software, which is compatible with various software packages/application development environments such as LabVIEW LabWindows/CVI or Measurement Studio compatibility makes it convenient for users to collect and analyze data.
In summary, The NI SCXI-1600 data acquisition module has become an important device in the field of data acquisition due to its high performance, ease of use, and wide range of applications.
