PM865K01容錯控制器,中文PDF用戶手冊PM865K01
從機規格
MVI56-MCM模塊接受Modbus功能代碼
來自連接的Modbus主設備。配置的端口
Modbus從機允許遠程主機進行交互PM865K01
模塊中包含的所有數據。此數據可以是源自上的其他Modbus從設備網絡，通過主端口，或從ControlLogix加工機
主規范
上配置為虛擬Modbus主設備的端口
MVI56-MCM模塊主動發布Modbus
Modbus網絡上其他節點的命令。一
每個端口支持100條命令。
此外，主端口具有優化的輪詢
通過通信輪詢從屬設備的特性
問題不太頻繁。ControlLogix處理器
可通過編程控制端口上的活動
從命令列表中主動選擇命令
直接從梯形圖執行或發出命令
思維方式
其他產品
ProSoft技術提供了
針對各種
工業通信平臺。兼容產品
inRAx產品線還包括：
具有精簡數據的Modbus通信模塊
塊（MVI56-MCMR）
Slave Specifications
The MVI56-MCM module accepts Modbus function code
commands of 1, 2, 3, 4, 5, 6, 8, 15, 16, 17, 22 and 23
from an attached Modbus master unit. A port configured
as a Modbus slave permits a remote master to interact
with all data contained in the module. This data can be
derived from other Modbus slave devices on the
network, through a master port, or from the ControlLogix
processor.
Master Specifications
A port configured as a virtual Modbus master device on
the MVI56-MCM module actively issues Modbus
commands to other nodes on the Modbus network. One
hundred (100) commands are supported on each port.
Additionally, the master ports have an optimized polling
characteristic that polls slaves with communication
problems less frequently. The ControlLogix processor
can be programmed to control the activity on the port by
actively selecting commands from the command list to
execute or issuing commands directly from the ladder
logic.
Additional Products
ProSoft Technology offers a full complement of
hardware and software solutions for a wide variety of
industrial communication platforms. Compatible products
in the inRAx product line also include:
Modbus Communication Module with Reduced Data
Block (MVI56-MCMR)
