功能規范
MVI56-HART模塊支持HART多點
議定書的實施。以下是一些
模塊的一般規格：LXN1604-6
?根據HART Bell 202頻率建造
移位鍵控（FSK）標準以疊加數字
4–20mA頂部低電平信號
o四個獨立的HART主端口
LXN1604-6中文PDF使用手冊
完全由用戶配置
o每個端口最多支持15個設備
o點到點（從地址0）或多點
（從地址1到15）支持的模式
?支持99種通用做法
每個端口用于控制和監視設備的命令
帶整數、IEEE754浮點和壓縮
ASCII字符串?dāng)?shù)據塊
?突發模式可用于更快地更新數據
從單個從機?支持自動輪詢功能
自動從每個HART收集數據
在通道上安裝儀表，并將數據存儲在
模塊數據庫
?通信端口可以配置為
輔助主機（即手持配置
設備）
支持的協議：HART協議使用Bell 202
標準移頻鍵控（FSK）數字信號
1200波特通信，低電平疊加
4至20mA模擬測量信號。
Functional Specifications
The MVI56-HART module supports the HART Multidrop
implementation of the protocol. Following are some
general specifications for the module:
? Built in accordance to the HART Bell 202 Frequency
Shift Keying (FSK) standard to superimpose digital
signals at a low level on top of the 4 – 20mA
o Four independent HART master ports that are
completely user-configurable
o Supports up to 15 devices per port
o Point-to-point (slave address 0) or Multidrop
(slave address 1 to 15) modes supported
? Supports 99 universal and common practice
commands per port to control and monitor devices
with integer, IEEE754 floating-point and packed
ASCII character string data blocks
? Burst mode can be used for faster update of data
from a single slave? Supports an auto polling feature that will
automatically collect data from each HART
instrument on the channel and store the data in the
module database
? Communication ports can be configured as a
secondary master (that is, handheld configuration
device)
Protocol Supported: HART protocol uses the Bell 202
standard frequency shift-keying (FSK) digital signal to
communicate at 1200 baud, superimposed at a low level
on the 4 to 20mA analog measurement signal.
