3BHE022455R1101耦合器,3BHE022455R1101控制卡輸入/輸出總線終端為便于更換故障RCM，應位于擴展總線末端，并使用專用終端電纜連接-目錄號IC697CBL803（3英尺（0.9米））?？梢栽趯?duì)擴展總線中斷最小的情況下移除此電纜，KSD211B 3BHE022455R1101耦合器尤其是當系統中包含一個或多個擴展機架時。使用電纜IC600WDXXX（其中XXX為表3所示的英尺長度）
連接擴展機架CPU機架中的總線發送器模塊（BTM）連接到擴展機架中的BRM。（適用于FIP單機架冗余系統以外的系統）。其他擴展機架通過BRM之間的菊花鏈布線添加，RCM始終最后連接。卸下模塊D時，用拇指放在板蓋的前部，手指放在板蓋背面的塑料夾子上，牢牢抓住板蓋的頂部和底部。KSD211B 3BHE022455R1101耦合器D用手指擠壓蓋背面的齒條夾，使其與齒條導軌分離
I/O Bus Termination
To allow for easy replacement of a faulty RCM, it should
be located at the end of the expansion bus and connected
using a special terminated cable - catalog number
IC697CBL803 (3 feet (0.9 meters). This cable can be
removed with minimal disruption of the expansion bus,
especially when one or more expansion racks are included
in the system.
Expansion Rack Attachment
Using cable IC600WDXXX (where XXX is length in feet
as shown in Table 3) a Bus Transmitter Module (BTM) in
the CPU rack connects to a BRM in an expansion rack.
(Appliocable if used in a system other than the FIP single
rack redundant system). Additional expansion racks are
added by daisy-chaining cabling between BRMs with the
RCM always connected last.
Removing a Module
D
Grasp the board firmly at the top and bottom of the
board cover with your thumbs on the front of the
cover and your fingers on the plastic clips on the back
of the cover.
D
Squeeze the rack clips on the back of the cover with
your fingers to disengage the clip from the rack rail
