HONEYWELL CC-PDIL01隔離模塊,CC-PDIL01中文使用說明
8點隔離模擬電壓源輸出模塊（HONEYWELL CC-PDIL01）容納
四個一組的兩個隔離組中的八個電壓輸出。它提供八個模擬通道
每個通道具有用戶可配置縮放的電壓輸出。
電壓源模擬輸出24 VDC 5K? 最小負載
支持8路輸出電壓，范圍從–10V到+10V，分辨率為14位。
提供的輸出超出范圍高達約10.25V。
同時使用字和位數據類型。
可現場重新校準或重置為出廠校準。所有校準數據存儲在
閃存。
單個通道配置，包括輸出范圍和縮放參數。
報告低于/超過范圍的故障。
HONEYWELL CC-PDIL01隔離模塊
電源
8點隔離模擬電壓源輸出模塊需要單獨的電源
輸出電源。
發光二極管
單個指示器顯示模塊狀態：
ON：正常運行
間歇性閃爍：模塊故障
關閉：無背板電源、無用戶電源或致命故障。
The 8 Point Isolated Analog Voltage-source Output Module (IC670ALG310) accommodates
eight voltage outputs in two isolated groups of four. It provides eight channels of analog
voltage outputs with user–configurable scaling for each channel.
VOLTAGE SOURCE
ANALOG OUTPUT
24 VDC 5K? MIN LOAD
Supports 8 channels of output voltages ranging from –10V to +10V with 14-bit resolution.
Output overrange provided for up to approximately 10.25V.
Uses both word and bit data types.
Can be field-recalibrated or reset to factory calibration. All calibration data is stored in
FLASH memory.
Individual channel configuration including output range and scaling parameters.
Reports Under/Overrange faults.
Power Sources
The 8 Point Isolated Analog Voltage-source Output Module requires a separate source of
power for the outputs.
LEDs
A single indicator shows module status:
ON: normal operation
Intermittent flashing: module fault
OFF: No backplane power, no user power, or fatal fault.
