Discrete switches and loads are usually two-wire devices. General practice is to terminate both
wires at the control panel. One side of discrete devices is usually a common supply or return tie
point. Field Control I/O Terminal Block and Auxiliary Terminal Block tie point connections
provide sufficient locations to accomplish this.
Suppression at the Output Load
Most solid state controls include load suppression within the output drive. AC solid state relays
and proximity switches turn off at low currents with some internal suppression. DC devices
usually specify suppression if not included with the device. Additional suppression is required if:
1.
The stored load energy to be dissipated exceeds the rating of the module's output
suppressor during the turn-off discharge time.
2.
A mechanical contact is used in series with a driven output coil. Install additional
suppression such as a series resistor-capacitor snubber to counteract electrical noise that
occurs when the coil is switched by the external contact instead of the module.
