DATX110通訊模塊,DATX110如何使用
所有現場控制輸入/輸出模塊的輸入/輸出設備都需要現場側電源。電源設備
在具有類似電源要求的模塊之間,DATX110可以輕松地“菊花鏈”連接。
任何一個螺釘上都有10安培的最大限值?;蛘撸梢允褂脝为?dú)的電源
在任何模塊組合上,根據需要提供隔離。

輸入/輸出模塊上電源連接的位置取決于模塊類型。對于
有關特定類型模塊電源連接的信息,請參閱其單個模塊
數據表。
熱插拔電源線
對于熱插入/移除模塊,必須關閉要插入的模塊的電源,或
遠離的。安裝過程中應提供斷開模塊電源的方法。
噪聲抗擾度
良好的布線實踐是可靠和可預測系統運行的基礎。
DATX110通訊模塊,DATX110如何使用
應使用第1章中列出的電氣環境標準作為基準。不受控制的
實際裝置中的組合效應、較高級別的噪聲或具有不同噪聲源的噪聲
標準中的屬性仍可能導致問題。因此,必須遵循
安裝中的謹慎布線和抑制實踐。
設備外部和電纜槽中的接線應按照公認的做法進行分離。
All Field Control I/O modules require field-side power for their I/O devices. Power supply
connections can easily be “daisy-chained” between modules with similar power requirements.
There is a 10 Amp maximum limit on any one screw. Alternatively, separate supplies can be used
on any combination of modules to provide isolation as needed.
The location of the power connection on an I/O module depends on the module type. For
information on power connection to a specific type of module, refer to its individual module
datasheet.
Power Wiring for Hot Insertion/Removal
For Hot Insertion/Removal of modules, power must be switched off to the module being inserted or
removed. A means of removing power to the module should be provided during installation.
Noise Immunity
Good wiring practices are the foundation for reliable and predictable system operation.
The electrical environmental standards listed in chapter 1 should be used as benchmarks. Uncontrolled
combinational effects in a real installation, higher levels of noise, or sources of noise with different
properties from those in the Standard can still cause problems. Therefore, it is important to follow
prudent wiring and suppression practices in the installation.
Wiring external to equipment and in cable trays should be separated following accepted practices.
