NI SCXI-1193 高密度RF繼電器模塊
1.產 品 資 料 介 紹：
中文資料：
NI SCXI-1193高密度RF繼電器模塊是一款專為與PXI任意波形發生器和PXI示波器等高頻儀器集成而設計的高性能模塊。以下是該產品的主要特點：
- 高密度設計：該模塊采用高密度設計，具有較小的體積和重量，方便集成到各種緊湊型設備和系統中。
- 多種配置選擇：該模塊可以通過編程配置為未端接多路復用器、外部端接多路復用器或尺寸靈活的稀疏矩陣，以滿足不同應用的需求。
- 高性能：該模塊能夠承受從DC到500 MHz以上的信號頻率，具有高精度和高穩定性的性能表現。
- 易于布線：該模塊具有一個插槽，利用高密度推進式MCX連接器進行離散但易于管理的布線，方便用戶進行線路連接和布局。
- 兼容性強：該模塊可以與其他工業設備和系統無縫連接，具有良好的兼容性和互操作性。
- 易于維護：該模塊設計簡潔，維護方便，能夠降低維護成本和停機時間。
綜上所述，NI SCXI-1193高密度RF繼電器模塊具有高密度、多種配置選擇、高性能、易于布線、兼容性強和易于維護等特點，適用于各種需要高集成度、高性能和穩定性的應用場景。
英文資料：
The NI SCXI-1193 high-density RF relay module is a high-performance module designed specifically for integration with high-frequency instruments such as PXI arbitrary waveform generators and PXI oscilloscopes. The following are the main features of this product:
High density design: This module adopts a high-density design, with a small volume and weight, making it easy to integrate into various compact devices and systems.
Multiple configuration options: This module can be programmed to be configured as an unterminated multiplexer, an externally terminated multiplexer, or a flexible sparse matrix to meet the needs of different applications.
High performance: This module can withstand signal frequencies from DC to over 500 MHz, with high precision and stability performance.
Easy to wiring: This module has a slot that utilizes high-density push on MCX connectors for discrete yet easy to manage wiring, making it convenient for users to connect and layout their wiring.
Strong compatibility: This module can seamlessly connect with other industrial equipment and systems, with good compatibility and interoperability.
Easy to maintain: This module is designed with simplicity and easy maintenance, which can reduce maintenance costs and downtime.
In summary, the NI SCXI-1193 high-density RF relay module has the characteristics of high density, multiple configuration options, high performance, easy wiring, strong compatibility, and easy maintenance, making it suitable for various application scenarios that require high integration, performance, and stability.
2.產 品 展 示
